For testing purposes, several image datasets are provided.
  1. PNC3: This dataset, courtesty of Matt Uyttendaele, consists of a panorama of 7 images resulting in an image of resolution 7,963 x 3,589.
    To obtain the gradient field, we execute:
    GradientComposite.exe --in images.txt --outX dx.half --outY dy.half --labels labels.png --hFill --positions srcpos.txt
    which gives an output of:
    Input Size: 7963 x 3589
    Average: 81.166594 94.873757 109.569944
    Given the desired gradient fields and the computed average color value, the best-fit image is obtained by running:
    GradientsToImage.exe --inX dx.half --inY dy.half --out pnc3.jpg --average 81.166594 94.873757 109.569944 --width 7963 --height 3589
    The resulting, stiched, image is:
    Note that since the --hFill flag was enabled when the gradient field was generated, the reconstruction smoothly extends the image into the unlabeled pixels.

  2. Edinburgh: This dataset, courtesty of Brian Curless, consists of a panorama of 25 images resulting in an image of resolution 16,950 x 2,956.
    To obtain the gradient field, we execute:
    Input:
    GradientComposite.exe --in images.txt --outX dx.half --outY dy.half --labels labels.png
    Output:
    Input Size: 16950 x 2956
    Average: 78.278509 96.306657 114.776703
    Input:
    GradientsToImage.exe --inX dx.half --inY dy.half --out edinburgh.jpg --average 78.278509 96.306657 114.776703 --width 16950 --height 2956
    Output:

    Note that since the --hFill flag was not enabled when the gradient field was generated, the reconstructed image preserves the boundary between the labeled and unlabeled pixels.

  3. Redrock: This dataset, courtesty of Aseem Agarwala, consists of a panorama of 9 images resulting in an image of resolution 19,588 x 4,457.
    To obtain the gradient field, we execute:
    Input:
    GradientComposite.exe --in images.txt --outX dx.half --outY dy.half --labels labels.png --lScale 20
    Output:
    Input Size: 19588 x 4457
    Average: 124.306111 117.633504 102.756149
    Input:
    GradientsToImage.exe --inX dx.half --inY dy.half --out redrock.jpg --average 124.306111 117.633504 102.756149 --width 19588 --height 4457
    Output:

    Note that since the label files has successive color indices changing by (20,20,20), we added the parameter --lScale 20.
